Cd / Md Single Speed Double Speed 15t 20t 50t Electric Wire Rope Hoist Electric Cable Hoist

Brand Name : JCYC

Model Number : CD/MD

Certification : CE ISO

Place of Origin : China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C,T/T,Western Union

Supply Ability : 300 sets per month

Delivery Time : 15 to 20 working days

Packaging Details : Standard export wooden cases

Product name : CD / MD 15T 20T 50T 5 Ton Electric Wire Rope Hoist High Speed Electric Cable Hoist

Model : CD/MD

Brand : JCYC/OEM

Capacity : 0.25 to 50T

Lifting speed : 0.8/8m/min; 8m/min

Color : Yellow; blue; red;orange

Contact Now

Cd / Md Single Speed Double Speed 15t 20t 50t Electric Wire Rope Hoist Electric Cable Hoist
Product Description:

CD and MD type wire rope electric hoist descriptions:
The CD and MD type wire rope electric hoist is a kind of light and small lifting equipment, which can be installed in single beam crane, bridge crane, gantry crane, cantilever crane, etc. They can meet the requirements of ordinary occasions.

The electric wire rope hoist model CD and MD have the features of compact, light, small-size shape and smooth operation. It can be used not only on the overhead rails, but also be used in conjunction with many types of electric or manual cranes such as the single-girder crane, the double girder crane, the cantilever crane and the gantry crane. The electric hoist model MD1 with double lifting speed should be used in cases where the hoist model CD1 with single speed cannot meet the requirements for fine adjusting during precision operations.

Product Parameters:
JCYC-CD1 Electric Wire Rope Hoist
Model Lifting Capacity (t) Lifting Height (m) Lifting Speed (m/min) Running Speed (m/min) Wire Rope Type Dia.of Wire Rope (mm) I Beam Track Type Working Duty Lifting Motor Running Motor
Power(kw) R.P.M ( r/min) Power Supply Power(kw) R.P.M ( r/min) Power Supply
CD1-0.25 0.25 3-9 8 20 6*19 3.6 16-22b M3 0.4 1380 220-440V 50/60HZ 3Phase 0.06 1400 220-440V 50/60HZ 3Phase
CD1-0.5 0.5 6-12 8 20 6*37+1 4.8 16-28b M3 0.8 1380 0.2 1380
CD1-1 1 6-30 8 20 6*37+1 7.4 16-28b M3 1.5 1380 0.2 1380
CD1-2 2 6-30 8 20 6*37+1 11 20a-32c M3 3 1380 0.4 1380
CD1-3 3 6-30 8 20 6*37+1 13 20a-32c M3 4.5 1380 0.4 1380
CD1-5 5 6-30 8 20 6*37+1 15 25a-63c M3 7.5 1380 0.8 1380
CD1-10 10 6-30 7 20 6*37+1 15 25a-63c M3 13 1400 0.8*2 1380
CD1-16 16 6-30 3.5 20 6*37+1 15 45a-63c M2 13 1400 0.8*2 1380
CD1-20 20 6-30 3.5 20 6*37+1 20 50a-63c M2 13 1400 0.8*2 1380
JCYC-MD1 Electric Wire Rope Hoist
Model Lifting Capacity (t) Lifting Height (m) Lifting Speed (m/min) Running Speed (m/min) Wire Rope Type Dia.of Wire Rope (mm) I Beam Track Type Working Duty Lifting Motor Running Motor
Power(kw) R.P.M ( r/min) Power Supply Power(kw) R.P.M ( r/min) Power Supply
MD1-0.25 0.25 3-9 8/0.8 20 6*19 3.6 16-22b M3 0.4 1380 220-440V 50/60HZ 3Phase 0.06 1400 220-440V 50/60HZ 3Phase
MD1-0.5 0.5 6-12 8/0.8 20 6*37+1 4.8 16-28b M3 0.2/0.8 1380 0.2 1380
MD1-1 1 6-30 8/0.8 20 6*37+1 7.4 16-28b M3 0.2/1.5 1380 0.2 1380
MD1-2 2 6-30 8/0.8 20 6*37+1 11 20a-32c M3 0.4/3.0 1380 0.4 1380
MD1-3 3 6-30 8/0.8 20 6*37+1 13 20a-32c M3 0.4/4.5 1380 0.4 1380
MD1-5 5 6-30 8/0.8 20 6*37+1 15 25a-63c M3 0.8/7.5 1380 0.8 1380
MD1-10 10 6-30 7/0.7 20 6*37+1 15 25a-63c M3 1.5/13 1400 0.8*2 1380
MD1-16 16 6-30 3.5/0.35 20 6*37+1 15 45a-63c M2 1.5/13 1400 0.8*2 1380
MD1-20 20 6-30 3.5/0.35 20 6*37+1 20 50a-63c M2 1.5/13 1400 0.8*2 1380
Product Packing:

Cd / Md Single Speed Double Speed 15t 20t 50t Electric Wire Rope Hoist Electric Cable Hoist

Cd / Md Single Speed Double Speed 15t 20t 50t Electric Wire Rope Hoist Electric Cable Hoist

Cd / Md Single Speed Double Speed 15t 20t 50t Electric Wire Rope Hoist Electric Cable Hoist

Cd / Md Single Speed Double Speed 15t 20t 50t Electric Wire Rope Hoist Electric Cable Hoist

Cd / Md Single Speed Double Speed 15t 20t 50t Electric Wire Rope Hoist Electric Cable Hoist
